wall-travelling-jib-crane
Wall travelling hanging crane
wall travelling jib crane
travelling jib crane
Wall travelling jib crane

BB Wall Travelling Jib Crane

Product Type: BB
Lifting Capacity: 0.5~16t
Arm Length: 1m~10m
Lifting Height: According your demands
Working Class: A3,A4,A5
Ambient Temperature: -20~40℃

Customized one is available, just contact us with your detailed requirements.

SEND INQUIRY

Overview

BB wall travelling jib crane is a light-duty lifting equipment combining wall-mounted and travelling functions. It moves along the horizontal track installed on the wall, with flexible rotation, suitable for long-distance local material handling in workshops and warehouses.

Introduction

Equipped with electric hoist as the core lifting mechanism, this crane supports horizontal travel and 270°/360° rotation. It features simple installation and convenient operation, applicable for 0.5-16tons load lifting in long-span local working areas, improving handling efficiency.

Features

  • Wall-travelling design, covers long working distance without occupying floor space
  • Dual functions of travel and rotation, wide working coverage
  • Light structure, stable operation and low maintenance cost
  • Equipped with safety limit devices, ensuring operation safety

Specification

Working Class A3,A4,A5
Capacity t 0.5~16
Arm Length m 1~8
Lifting Height m 3~100
Lifting Speed m/min 0.33~8, Single or Dual Speed
Trolley Travelling Speed m/min 2~30, Single or Dual Speed
Power Supply 380V 50HZ 3PHASE or Customized
Temperature ℃ -20~60
Protection Grade IP44~65
The above are standard parameters, and customized solutions and designs are provided according to your actual needs.

Structural Component

  • Jib Arm: High-strength steel, core load-bearing component
  • Electric Hoist: Core lifting part, responsible for lifting and lowering
  • Wall-mounted Track & Travelling Mechanism: Realize horizontal travel of the crane
  • Rotating Mechanism: Enable flexible rotation of the jib arm
  • Control System: Pendant or remote control for convenient operation

Product Sketch

Product sketch
