PRODUCTS

Portable Gantry Crane

Lifting Capacity:	0.25~10t
Span:	2~12m
Lifting Height:	1~9m
Working Class:	A3,A4
Ambient Temperature:	-20~40℃

Customized one is available, just contact us with your detailed requirements.

Overview

Portable gantry crane is a lightweight, movable lifting equipment. No fixed installation required, it is ideal for temporary material handling in workshops, construction sites, maintenance yards and small warehouses.

Introduction

Equipped with electric or manual hoist as the core lifting mechanism, this crane features simple assembly and flexible movement. It is suitable for lifting 0.25-10 tons of loads, effectively solving mobile lifting needs in various temporary workplaces.

Features

Lightweight and portable, easy to move and store
No foundation required, quick assembly and deployment
Simple operation, adaptable to multiple work scenarios
Equipped with braking devices, ensuring stable and safe operation

Specification

Working Class		A3,A4
Capacity	t	0.25~10
Span	m	2~10
Lifting Height	m	1~6
Lifting Mechanism		Hand Hoist，Electric Hoist
Control Method		Ground Control
Temperature	℃	-20~60
Material		Stainless Steel, Aluminum Alloy, Carbon Steel
The above are standard parameters, and customized solutions and designs are provided according to your actual needs.

Structural Component

Gantry Frame: High-strength steel, detachable design, core load-bearing component
Hoist: Electric/manual hoist, core lifting part
Casters: Heavy-duty universal wheels with brakes, ensuring flexible movement and positioning
Control System: Pendant or manual control, simple and convenient to operate
